New technological sliding system for windows and doors

• Space-saving
• Panoramic view
• Energy efficiency
• High airtightness
• Reliability and security

Applications

The WDS SL 76 sliding windows and doors are a cutting-edge, warm solution for private homes and apartments, ideal for terrace doors, modern balcony units, and windows.

Smooth and easy sash movement: the sash effortlessly slides parallel to the frame along the guide rail.

Reliable airtightness: uses window seals to ensure durability.

High level of airtightness and sound insulation: enhanced insulation provided by special hardware and continuous sealing around the entire perimeter of the sash.

Maximum frame dimensions (width):

• for white profile structures - 4,000 mm
• for structures made of non-ferrous profiles:

in case of welded connection of frame corners - 3 000 mm

with mechanical connection of frame corners - 4 000 mm

Technical specifications:

• System thermal conductivity coefficient (Uf) up to 1.3 W/m?K
• 32 mm, 40 mm, 48 mm glazing unit
• 5 chambers in the sash
• 24 lamination colors
• Air permeability: Class 4
• Water tightness: Class 8A
• Wind load resistance: Class C2/B2
• Maximum dimensions: 4000 x 2500 mm
